High Accuracy 200ton Pneumatic Power Press Machine for Metal Stamping

  • 1
  • 2
  • 3

Brand Name : QIAOSEN

Model Number : ST-200V

Certification : CE / ISO14001

Place of Origin : China

MOQ : 1

Price : Price $4,685/cases 1-2 cases

Payment Terms : T/T

Supply Ability : 100SET per month

Delivery Time : 25-60

Packaging Details : WOODEN BOX

Weight : 3.8 tons

Dimensions (L×W×H) : 1575×950×2500 mm

Motor Power : 5.5 kW

Voltage : 380V

Punching Capacity : 200 ton

Contact Now

High Precision Pneumatic Punching Machine
Professional 200-ton pneumatic punching machine designed for tin can lid production and high-quality metal bearing manufacturing used in motor pumps and engines.
Product Specifications
Machine Type Punching Machine
Power Source Pneumatic
Voltage 380V
Motor Power 5.5 kW
Model Number ST-200V
Weight 3.8 tons
Dimensions (L×W×H) 1575×950×2500 mm
Place of Origin Guangdong, China
Brand Name QIAOSEN
Technical Performance Data
Parameter Unit V Type H Type
Punching Capacity ton 200
Impact Force Location mm 6 3
Slider Strokes per Minute SPM 20-50 50-70
Slider Length mm 200 100
Max Die Shut Height mm 460 510
Slider Adjustment Amount mm 110
Up Platform Area mm 1130×630×90
Down Platform Area mm 1400×820×160
Main Motor Power kW×p 18.5×4
Air Pressure kg/cm² 6
Punch Weight ton 23
Performance Features
  • High-strength fuselage structure with minimal deformation and high precision
  • OMPI pneumatic dry clutch brake system
  • Slider with 2-corner and 6-sided guides for enhanced stability
  • Slider guide featuring high-frequency quenching and rail grinding process for reduced wear and extended service life
  • Crankshaft made of high-strength alloy 42CrMo (1.3 times stronger than 45 steel)
  • Copper sleeve made of tin phosphor bronze ZQSn10-1 (1.5 times stronger than ordinary BC6 brass)
  • Highly sensitive hydraulic overload protection device for press and die longevity
  • Optional air cushion available
Product Configuration
High Accuracy 200ton Pneumatic Power Press Machine for Metal Stamping
Warranty & Service
  • One year warranty for complete press machine
  • Comprehensive spare parts availability
  • International brand electrical components
  • Technical training and consulting via email, phone, or video
  • On-site engineer service available
  • English operation and maintenance manual included
  • Certificate of conformity provided
Quality Assurance
Machinery test report and video outgoing-inspection provided
High Accuracy 200ton Pneumatic Power Press Machine for Metal Stamping
