High Accuracy Pneumatic Stamping Machine 45ton for Metal Sheet Production

Price : $12,716/cases 1-2 cases

cnc or not : Normal

machine type : Punching Machine

slide stroke (mm) : 80

power source : Pneumatic

place of origin : Guangdong, China

brand name : QIAOSEN

voltage : 380V

dimension(l*w*h) : 1575*950*2500

motor power (kw) : 5.5

model number : ST-45v

weight (t) : 3.8

key selling points : High-Accuracy

warranty : 1 Year

machinery test report : Provided

video outgoing-inspection : Provided

core components : Bearing, Pump, Gear, Motor, PLC, Pressure Vessel, Engine

punching capacity : 45ton for stamping machines

Slider adjustment amount : 60mm for metal straightening machine

Up platform area : 560*340*60mm for number plate making machine

Down platform area : 850*440*80mm for power press

Slider center to machine distance : 225mm for perforation machine

Platform to floor distance : 790mm for press machine pneumatic

Main motor power : 5.5*4 for manual press stamping machines

Air pressure : 6 for power press machine

Punch dimension(L*W*H) : 1575*950*2500mm for pneumatic press

Punch weight : 3.8tons for tube punching machine

Place of Origin : China

Brand Name : QIAOSEN

Certification : CE / ISO14001

Contact Now

ST-45ton V Type Pneumatic Stamping Machine
Product Overview

This is a 45-ton open single point crank punching machine that meets Japanese JIS 1 class standards for safety, energy saving, stability, automation, and high precision.

High Accuracy Pneumatic Stamping Machine 45ton for Metal Sheet Production
Performance Features
  • High-strength fuselage structure with minimal deformation and high precision
  • OMPI pneumatic dry clutch brake system
  • Slider utilizes 2-corner and 6-sided guides
  • Slider guide features high-frequency quenching and rail grinding process for minimal wear, high precision, extended precision maintenance time, and improved service life
  • Crankshaft made of high-strength alloy 42CrMo, 1.3 times stronger than 45 steel
  • Copper sleeve made of tin phosphor bronze ZQSn10-1, 1.5 times stronger than ordinary BC6 brass
  • Highly sensitive hydraulic overload protection device protects press and die service life
  • Optional mat (air cushion) available
High Accuracy Pneumatic Stamping Machine 45ton for Metal Sheet Production
Technical Specifications
No Item Unit ST-45 V Type ST-45 H Type
1 Punching Capability ton 45
2 Impact Force Location mm 3.2 1.6
3 Slider Strokes Per Minute SPM 40-100 110-150
4 Slider Length mm 80 50
5 Max Die Shut Height mm 250 265
6 Slider Adjustment Amount mm 60
7 Up Platform Area kN 560×340×60
8 Down Platform Area ml 850×440×80
9 Shank Hole N.m Ø38.1
10 Main Motor Power kw×p 5.5×4
11 Air Pressure kg/cm² 6
12 Punch Accuracy Grade JIS 1
13 Slider Adjustment Device Manual Operation
14 Slider Center to Machine Distance mm 225
15 Platform to Floor Distance mm 790
16 Punch Weight ton 3.8
Related Products
High Accuracy Pneumatic Stamping Machine 45ton for Metal Sheet Production High Accuracy Pneumatic Stamping Machine 45ton for Metal Sheet Production High Accuracy Pneumatic Stamping Machine 45ton for Metal Sheet Production High Accuracy Pneumatic Stamping Machine 45ton for Metal Sheet Production High Accuracy Pneumatic Stamping Machine 45ton for Metal Sheet Production
Product Configuration
High Accuracy Pneumatic Stamping Machine 45ton for Metal Sheet Production
Warranty and Service
  • One year warranty for whole press machine
  • All spare parts available as most parts produced by our factory
  • Easy access to electric parts as all are international famous brands
  • Technical training and consulting available via email, phone, or video
  • Engineers available for service, installation, or training with reasonable additional cost
  • English operation and maintenance manual provided with the press
  • Certificate of conformity included with press
Frequently Asked Questions
Who are we?

Our factory is located in Wuxi, China with a branch company in Dongguan. Established in 2016, we serve Southeast Asia (50%), Mid East (30%), Africa (10%), South Asia (5%), Northern Europe (4%), and Eastern Europe (1%). Our office employs 51-100 people.

Why select us?

We are a high-end quality punching machine manufacturer and we promise customers will never regret choosing our brand.

How about your delivery time?

Usually takes about 25 to 40 working days after receiving your advance payment.

Do you provide after-sale service?

Our technical and quality team will support you anytime you need assistance.

Can I do different color machine?

Yes, we can customize colors to match your production line requirements.

Can the touch screen board language change to others?

Yes, we can configure languages according to your requirements including Spanish, French, etc.
